Air Receiver Tank
Description
Introducing our durable Air Receiver Tanks, ranging from 300 to 10,000 Litres. Choose from optional internal and external epoxy coatings for added protection against corrosion. Trust in our quality for your air storage needs.
Air Receiver Tank Specifications
| VOLUME(LITER) | MAX. PRESSURE (BAR) | DIMENSIONS (MM) | INSPECTION OPENING | CONNECTIONS | WEIGHT (KG) | ||
| OD | SHELL HEIGHT | OVERALL HEIGHT | |||||
| 300 | 10 | 488 | 1524 | 2152 | 2″ SOCKET x 2 NOS | 2″ SOCKET | 118 |
| 500 | 10 | 605 | 1524 | 2208 | 2″ SOCKET x 2 NOS | 2″ SOCKET | 163 |
| 750 | 10 | 605 | 1830 | 2508 | 2″ SOCKET x 2 NOS | 2″ SOCKET | 269 |
| 1000 | 10 | 780 | 1830 | 2584 | 2″ SOCKET x 2 NOS | 2″ SOCKET | 356 |
| 1500 | 10 | 930 | 1830 | 2680 | 4.5″ x 6.25″ HANDHOLE | 3″ FLANGE | 600 |
| 2000 | 10 | 930 | 2440 | 3288 | 4.5″ x 6.25″ HANDHOLE | 3″ FLANGE | 659 |
| 3000 | 10 | 1166 | 2438 | 3405 | 12″ x 16″ MANHOLE | 3″ FLANGE | 879 |
| 4000 | 10 | 1320 | 2438 | 3485 | 12″ x 16″ MANHOLE | 4″ FLANGE | 1011 |
| 5000 | 10 | 1478 | 2438 | 3562 | 12″ x 16″ MANHOLE | 4″ FLANGE | 1121 |
| 6000 | 10 | 1601 | 2438 | 3623 | 12″ x 16″ MANHOLE | 4″ FLANGE | 1350 |
| 8000 | 10 | 1830 | 2438 | 3741 | 12″ x 16″ MANHOLE | 6″ FLANGE | 2050 |
